Floor size and weight: 2260L × 3122Wx2440H, approximately 700Kg
Applicable wire diameter AWG # 24~# 18
Wire delivery method: pull the wire
Wire processing length of 50-500mm (long wires over 500mm require conveyor belts)
Peel length 1.0-8mm
Pressure capacity 2.0T per unit
Pressure terminal JAM, JST type horizontal feeding terminal (standard JAM mold installation accessories)
Applicable rubber seat external dimensions customized according to size
Production capacity of 3.6 seconds per piece (when the wire cutting length is within 200mm)
Cutting and stripping methods: positive and negative lead screws
The handling method is linear motor trolley operation, with two trolley clamps, high position accuracy, and flexible movement
Assembly method: sequential assembly
Quality inspection function: Terminal visual monitoring, pressure monitoring, and assembly in place monitoring
Rubber seat feeding method: vibrating disc feeding
Seven workstations and two sets of carts for operation
Pressure requirement: 0.5-0.7MPa
Power interface 220V
