Footprint dimensions and weight: L3200 mm × W3300 mm × H2200 mm, approximately 600 kg (excluding pay-off rack)
Applicable wire cross-sectional area: 0.35–0.75 mm²
Wire feeding method: synchronous belt traction
Wire processing length: 280–1500 mm
Stripping length: double-ended, 1.0–15 mm
Crimping capacity: two 3.0-ton servo crimping machines, compatible with 30 mm and 40 mm stroke
Crimping dies: standard OTP or AMP, European-style dies with 40 mm stroke
Productivity: efficiency of 850 sets/hour at a wire cutting length of 1.5 m
Stripping method: bidirectional lead screws
Handling method: servo-driven trolley operation equipped with matching trolley clamps, ensuring high positional accuracy
Quality Inspection Functions: wire feed missing alarm, wire feed stop signal feedback, terminal pressure monitoring, and process action completion feedback
Wire Harness Feeding Method: manual coil feeding and threading preparation; automated wire feeding for production
Operating Stations: ten stations plus four trolley assemblies
Pneumatic Requirements: 0.5–0.7 MPa of dry, clean compressed air
Power Supply Interface: 380 V
