Footprint and Weight: 5100 mm (W) × 2100 mm (D), approximately 2000 kg
Applicable Wire Cross-Section: 0.2 mm²–2.5 mm²
Wire Feeding Method: Feed Wheel Wire
Processing Length: 195–3000 mm
Stripping Length: Double-end 1.0–20 mm
Crimping Force: 2.0 T
Crimping Terminals: JAM-type transverse feed terminals (compatible with JST and Molex terminals by replacing punch and die) / straight feed terminals Compatible with TE Special Molds
Production Rate: 3.5 seconds per piece (for wire cut length ≤ 1000 mm)
Stripping Method: Bidirectional Lead Screws
Handling Method: Operates via synchronous belt with three sets of trolley clamps, providing high positioning accuracy
Assembly method: sequential assembly and cross assembly (selectable within spatial constraints)
Quality inspection functions: visual inspection of terminal appearance, visual inspection of stripping length, pressure monitoring, and assembly position detection
Connector housing feeding method: manual feeding
Operating stations: ten stations (five crimping machines) plus three trolley units
Air pressure requirement: 0.5–0.7 MPa
Power interface: 380 V
Other functions: capable of integration with MES system
